FATRAFOL 790H
FATRAFOL 790H is an unreinforced, UV-resistant PVC-P swimming pool membrane. It is used for pool detailing, complementing the main FATRAFOL 790 waterproofing membrane. It has a smooth, matt blue surface.
- Supplementary membrane for pool details
- Not intended for waterproofing the main pool surfaces
- Resistant to sunlight and chlorine
Characteristics
Supplementary detailing membrane
Used for waterproofing pool details as a complement to the main FATRAFOL 790 membrane.
Unreinforced membrane
The membrane is made from plasticised PVC (PVC-P) without a reinforcing scrim. It is 2 mm thick and has a minimum elongation of 300%.
Colour fastness to chlorine
The membrane’s colour fastness when exposed to chlorine has been verified by testing in accordance with ČSN EN 15836.
Smooth, matt surface
The membrane has a smooth, matt surface in PANTONE 2915 blue.
Also suitable for outdoor swimming pools
The membrane is resistant to UV radiation when used in outdoor swimming pools.
Resistance to microorganisms
The material’s resistance to the effects of microorganisms has been verified by testing in accordance with ČSN EN ISO 846.
Technical specifications
Thickness | Width (mm) | Length (m) | Quantity (m2) |
|---|---|---|---|
2,0 | 1200 | 25 | 18 |
The membrane is installed in accordance with the FATRAFOL-B design and installation specification in force at the time the waterproofing work is carried out.
